Fpv 15 inch 4 axis traverser

Fpv 15 inch 4 axis traverser
Thumbnail 1
Thumbnail 2
Thumbnail 3
Maximum speed
130 km/h
Maximum flight range up to
15 km*
Flight time up to
42 min*
Warhead weight
8 kg
Professional-grade 15-inch FPV drone with maximum range and payload capacity.

Tactical and Technical Specifications

  1. Maximum speed: 130 km/h
  2. Rated Load: 7 kg
  3. Max Load: 8 kg
  4. VXT (Video Transmission): 15 km*
  5. Empty endurance: 42 min*
  6. Rated Load time: 12 min (2×8s 8000mah, 11.8 kg)
  7. Product size: 517×517×80 mm
  8. Wheelbase: 647 mm
  9. Arm Thickness: 10 mm
  10. Net Weight: 2050 g
  11. Package: 560×560×140 mm
  12. Package weight: 2700 g

*Depending on battery capacity, weather conditions, payload weight, and operator's control style.

Control and Video Transmission

  1. FPV Camera: 1800TVL 5-40V (Optional)
  2. Antenna: 5.8G Right-hand circular polarization SMA inner pin, length 150mm
  3. Receiver: ELRS915M

Drone Components

  1. Motor: 4× 4214 380kv 8S
  2. Flight Control: F4 F405 (Supports firmware: BF/INAV)
  3. ESC: 80A Single unit 3-8S
  4. Propeller: 1507 3-blade (4 pcs)
  5. Recommended Lipo Battery: 2×8S 8000mah 30C (2.04kg)

Additional Info

Professional-grade 15-inch FPV drone with maximum range and payload capacity, equipped with heavy-duty payload release system.
