13inch Fpv Drone

Maximum speed
135 km/h
Maximum flight range up to
28 km*
Flight time up to
24 min*
Warhead weight
4.5 kg
Versatile 13-inch FPV drone platform optimized for various mission profiles.
13inch Fpv Drone
Thumbnail 1
Thumbnail 2
Thumbnail 3

Tactical and Technical Specifications

  1. Optimal payload: 3.5 kg
  2. Maximum payload: 4.5 kg
  3. Flight time: up to 24 min*
  4. Operational range with payload (round trip): up to 14 km*
  5. Maximum one-way flight range: up to 28 km*
  6. Cruising speed: 75 km/h
  7. Maximum speed: 135 km/h
  8. Operating flight altitude: 50–350 m
  9. Maximum flight altitude: up to 2800 m

*Depending on battery capacity, weather conditions, payload weight, and operator's control style.

Control and Video Transmission

  1. Drone control type: ELRS or TBS
  2. Video transmission type: analog or digital
  3. Camera type: analog, digital (DJI O3/O4 or Walksnail Avatar GT), or thermal (Caddx IRC-640CA or Caddx IRC-384CA)

Drone Components

  1. 13-inch carbon frame
  2. Brushless motors: 4114 700KV
  3. Electronic Speed Controllers (ESC): 60A
  4. FPV camera — depending on configuration
  5. Video transmitter (VTX): from 1.2 to 2.5 W
  6. Propellers: 1345

Additional Info

The 13-inch FPV drone offers an excellent balance between payload capacity, flight time, and maneuverability. Equipped with a 6s4p battery and versatile payload mounting system.
